Thermosheet / Thermofilm

Nexteck's cover Tape material is available in carrier tape widths from 5.3mm to Jumbo(950mm).

Recommended storage conditions for carrier tape include storage indoors away from direct sunlight within a temperature range of 18° to 35° C (64 to 95° F) and relative humidity levels between 35% – 65%.

Thermosheet

- It offers excellent balance between mechanical strength and moldability, and can be used in applications such as complex forms and deep-drawing shapes.

- It consists of 3 layers with stable electrical conductivity for enhanced anti-static effectiveness

- Grades with higher wear resistance are also available, for preventing contamination of semiconductors, electronic components, etc.

Thermofilm

- Peels off with a steady force, making it easy to adjust sealing parameters for the optimal fit.

- Various grades are available, such as products treated to prevent static electricity, etc.

- ATA grade is highly transparent, providing excellent visibility of contents, while at the same time it generates little static electricity through friction with epoxy-sealed components, thus it is an effective antistatic resource for components.
